Speakers Selection for Immersive Audio Systems: Key Considerations
When designing an immersive audio system, selecting the right speakers is crucial to achieving high-quality sound reproduction. Chapter 6 of the “CEDIA/CTA-RP22 Immersive Audio Design” recommended practice outlines essential factors to consider when choosing speakers. Below, we break down the key aspects of speaker performance and selection to help you make informed decisions for your audio setup.
1. Speaker Performance Metrics
The performance of a speaker is evaluated based on several critical parameters, each influencing the overall audio experience:
- Frequency Response: How evenly the speaker reproduces sound across the audible spectrum.
- Directivity Index: The degree to which sound is focused in a particular direction.
- Sound Power: The total acoustic energy radiated by the speaker.
- Dispersion: How widely sound is spread horizontally and vertically.
- Inter-Speaker Phase Coherence: Ensures speakers work together seamlessly for accurate sound imaging.
- Maximum SPL Capacity: The loudness a speaker can achieve without distortion.
To assess these factors, manufacturers and standards provide key measurement data, including:
A. “Spinorama” (ANSI/CTA-2034-A)
This standardized test measures a speaker’s performance across 70 microphone positions, providing six key metrics:
1. On-Axis Frequency Response – Direct sound at the listener’s position.
2. Listening Window – Average response across a small listening area (±10° vertical, ±30° horizontal).
3. Early Reflections – Estimates first reflections in a typical room.
4. Sound Power – Total acoustic energy output.
5. Sound Power Directivity Index (SPDI) – Difference between listening window and sound power.
6. Early Reflection Directivity Index (ERDI) – Difference between listening window and early reflections.
A smooth, consistent response across these metrics indicates a well-designed speaker.
B. Speaker Dispersion Heat Map
A visual representation of how sound spreads from the speakers. This helps predict coverage and consistency across seating positions.
2. Inter-Speaker Phase Coherence
For immersive audio, speakers must work together to create precise sound localization. Mismatches in polarity, phase, or group delay between speakers can degrade performance:
– Polarity Mismatch: Occurs if a speaker’s wiring is reversed (+/- swapped), disrupting phantom imaging.
– Phase Mismatch: Causes frequency-dependent amplitude loss (e.g., 90° shift = 6 dB loss).
– Group Delay Mismatch: Time-based offsets between frequencies, blurring sound imaging.
Solution: Use speakers with similar phase characteristics or employ processors with “rephasing” capabilities.
3. Speaker Maximum SPL Capacity
Speakers must handle dynamic peaks in movies and music without distortion. Key considerations:
A. Acoustic Source & Propagation Loss
- Point Sources (most home speakers) lose ‘6 dB per doubling of distance’.
- Line Sources (e.g., vertical arrays) lose 3 dB per doubling but are rare in residential setups.
B. Calculating SPL at Listening Positions
Example: A speaker with ‘96 dB sensitivity at 1W/1m’ and ‘500W peak power’:
1. ‘500W ≈ +27 dB’ over 1W → ‘123 dB max at 1m’.
2. At 4m distance, propagation loss = 12 dB → 111 dB peak at RSP.
C. Performance Level SPL Targets
| **Parameter** | **Level 1** | **Level 2** | **Level 3** | **Level 4** |
|—————————–|————|————|————|————|
| **Screen Speakers (dB SPL)** | 99 min | 102 min | 105 min | 108 min |
| **Non-Screen Speaker** | 96 min | 99 min | 102 min | 105 min |
| **LFE (Subwoofers)** | 109 min | 112 min | 115 min | 118 min |
**Note**: Bass management and room gain can further influence subwoofer performance.
—
4. Practical Speaker Selection Tips
1. Match Speaker Types – Avoid mixing 2-way and 3-way speakers in the same system.
2. Prioritize Directivity – Wide dispersion improves off-axis performance for multi-seat setups.
3. Consider Room Acoustics – Reflective surfaces may require speakers with controlled directivity.
4. Verify Power Handling – Ensure speakers and amplifiers can deliver required SPL without clipping.
Final Thoughts
Choosing the right speakers involves balancing ‘tonal accuracy, spatial resolution, and dynamic range’. By leveraging standardized measurements like ‘Spinorama’ and ensuring ‘phase coherence’, you can design an immersive audio system that delivers a lifelike, enveloping experience.
For more details, refer to the full **CEDIA/CTA-RP22** guidelines or consult an audio design professional.
